Eco 24 Multi Zone Panel

Aquilar / Eco 24 Multi Zone Panel

EcoLeak Eco-24

ECO-24
	24 Independent sensing zones 4 channels of 6 zones Audible + visual alarms per zone Independent channel volt-free relays (4) Plug and play Operation Can be used as a centralised monitoring panel for AT-SRG refrigerant leak detection, or as a Multi Zone water leak detection panel Water sensing probes, max 1 / zone Water sensing cable, max 30m / zone Refrigerant gas sensors, max 1 / zone Simple zone enable/disable via dip switches BMS interface Leak and fault alarm relays Water shut-off (solenoid valve) Dedicated additional sounder beacon output Integrated 12Vdc accessory output (i.e powering AT-RAP, AT-SRG, AT-BCN-A) Battery Backup can be simply added to the panel to provide instant battery power in case of power disruption. In the event of multiple or simultaneous leaks, all zones operate individually and can report all events accurately.	Click for Datasheet Click for Installation & Operation Instructions Click for Product Brochure Click for Commissioning Form (Interactive) Click for Commissioning Form (Printable)

TECHNICAL INFORMATION
Sensing cable compatibility	EcoLeak sensing cable (1m to 30m)
Detection probes	EcoLeak Probes
Refrigerant sensor	Refrigerant gas probe AT-SRG
Maximum sensing circuit	30 metres sensing cable per zone or 1 x EcoLeak Probe per zone or 1 x AT-SRG refrigerant sensor per zone
Maximum jumper/leader cable length	300 meters per zone
Number of zones	24 (4 channels of 6)
Sensing circuit	2 wire sensing
Network capabilities	ECO-24 panel can monitor up to 24 no ECO-24 panels via ECO-NET
Enclosure	Powder coated steel, colour RAL 9016 Matt white, lockable
Cable entries	26No 20mm, 8No 25mm
Dimension and weight	315 x 270 x 100mm W x H x D, 3.5Kg
Working temperature	5°C to 40°C non-condensing
Humidity	5% to 95% non-condensing
Power supply	230/120Vac, 50/60Hz,12Vdc, 6 watts
Audible alarm	90db at 10cm
Relay output	Number: 12 Total 4 x Channel relays for Leak 4 x Channel relays for Fault 2 x common Leak 1 x common fault 1 x common for remote Sounder (leak or fault) Type SPDT, Rated at 3A at 250Vac / 24Vdc
Status LED	Power (Mains-Green), Leak (Red), Fault (Yellow)
Battery backup	Optional separate unit, providing up to 24 hour, AT-PSU-12-3 + AT-BAT
